The incoming dry bottles (sterilized and siliconised) are fed through the in-feed turn table and suitably guided on the moving SS/Plastic slat conveyor belt at the required speed of the correct placement below filling unit. Four bottles in a raw are held by pneumatic stoppers at a time below the filling nozzles. During the stationary position, the set fill volume is delivered into bottles. After filling, the filled bottle moving in star wheel pick up cap from the cap chute and move under the Capping head for perfect SCREW Capping.
AUTOMATIC 4 x 1 HEAD LINEAR BOTTLE LIQUID FILLING & SCREW CAPPING MACHINE (MONOBLOCK)
MODEL: MBFSC 4x1
Technical Specifications:
Machine Model |
MBFSC 4x1 |
|
No. of Heads/Syringes |
Four |
|
No. of Capping Head |
One |
|
Fill Capacity |
50ml to 250ml with the help of change parts |
|
Fill Accuracy |
+ 1% |
|
Output/Minute |
25 to 50 Bottles depending on viscosity & fill volume |
|
Working direction |
Left to Right |
|
Electric Characteristic |
Main Motor |
2 HP/230V/1440 RPM/Single Phase/50 Hz |
Conveyor Motor |
0.5 HP/230V/1440 RPM/Single Phase/50 Hz |
|
Power Supply |
Single Phase/3 Phase, 4 Wire |
|
Input Specifications |
Bottle dia. |
20mm to 75mm |
Bottle height |
25mm to 170mm |
|
Overall dimensions |
2460 mm L x 856 mm W x 2500 mm H |
|
Net Weight |
900 Kgs. |
|
Gross Weight |
1200 kgs. |
|
(The above specifications may change with the inclusion of latest technologies)
