On-line filled & capped containers are fed in to machine via single conveyor divided in equal quantum in further movement on two lines for visual inspection by operators. Black and white background helps them to inspect the bottle visually. On inspection the bottles are placed on center conveyor for outlet.
ON-LINE VISUAL INSPECTION MACHINE
MODEL: INS-2
Technical Specifications:
Machine Model |
INS-2 |
No. Operator |
Two |
Electric Characteristic |
0.5 HP/230V/1440 RPM/Single Phase/50 Hz |
Power Supply |
Single Phase/3 Phase, 4 Wire |
Overall dimensions |
875mm L x 865mm W x 1625mm H |
Net Weight |
120 kgs. |
Gross Weight |
350 kgs. |
(The above specifications may change with the inclusion of latest technologies)
