AUTOMATIC 4 x 1 HEAD LINEAR BOTTLE LIQUID FILLING & ROPP CAPPING MACHINE (MONOBLOCK)

MODEL: MBFRC 4x1

The incoming dry bottles (sterilized and siliconised) are fed through the in-feed turn table and suitably guided on the moving SS/Plastic slat conveyor belt at the required speed of the correct placement below filling unit. Four bottles in a raw are held by pneumatic stoppers at a time below the filling nozzles. During the stationary position, the set fill volume is delivered into bottles. After filling, the filled bottle moving in star wheel pick up cap from the cap chute and move under the Capping head for perfect ROPP Capping.

Technical Specifications:

Machine Model

MBFRC 4x1

No. of Heads/Syringes

Four

No. of Capping Head

One

Fill Capacity

50ml to 250ml with the help of change parts

Fill Accuracy

+  1%

Output/Minute

25 to 50 Bottles depending on viscosity & fill volume

Working direction

Left to Right

Electric Characteristic

Main Motor

2 HP/230V/1440 RPM/Single Phase/50 Hz

Conveyor Motor

0.5 HP/230V/1440 RPM/Single Phase/50 Hz

Power Supply

Single Phase/3 Phase, 4 Wire

Input Specifications

Bottle dia.

20mm to 75mm

Bottle height

25mm to 170mm

Overall dimensions

2460 mm L x 856 mm W x  2500 mm H

Net Weight

900 Kgs.

Gross Weight

1200 kgs.

(The above specifications may change with the inclusion of latest technologies)

AUTOMATIC 4 x 4 HEAD LINEAR BOTTLE LIQUID FILLING & ROPP CAPPING MACHINE (MONOBLOCK)

MODEL: MBRC 4x4

The incoming dry bottles (sterilized and siliconised) are fed through the in-feed turn table and suitably guided on the moving SS/Plastic slat conveyor belt at the required speed of the correct placement below filling unit. Four bottles in a raw are held by pneumatic stoppers at a time below the filling nozzles. During the stationary position, the set fill volume is delivered into bottles. After filling, the filled bottle moving in star wheel pick up cap from the cap chute and move under the Capping head for perfect ROPP Capping.

Technical Specifications:

Machine Model

MBFRC 4x4

No. of Heads/Syringes

Four

No. of Capping Head

Four

Fill Capacity

50ml to 250ml with the help of change parts

Fill Accuracy

+  1%

Output/Minute

25 to 80 Bottles depending on viscosity & fill volume

Working direction

Left to Right

Electric Characteristic

Main Motor

2.75 HP/230V/1440 RPM/Single Phase/50 Hz

Conveyor Motor

0.5 HP/230V/1440 RPM/Single Phase/50 Hz

Power Supply

Single Phase/3 Phase, 4 Wire

Input Specifications

Bottle dia.

20mm to 75mm

Bottle height

25mm to 170mm

Overall dimensions

3400 mm L x 1156 mm W x 2500 mm H

Net Weight

1450 kgs.

Gross Weight

1750 kgs.

(The above specifications may change with the inclusion of latest technologies)

AUTOMATIC 6 x 6 HEAD LINEAR BOTTLE LIQUID FILLING & ROPP CAPPING MACHINE (MONOBLOCK)

MODEL: MBFRC 6x6

The incoming dry bottles (sterilized and siliconised) are fed through the in-feed turn table and suitably guided on the moving SS/Plastic slat conveyor belt at the required speed of the correct placement below filling unit. Six bottles in a raw are held by pneumatic stoppers at a time below the filling nozzles. During the stationary position, the set fill volume is delivered into bottles. After filling, the filled bottle moving in star wheel pick up cap from the cap chute and move under the Capping head for perfect ROPP Capping.

Technical Specifications:

Machine Model

MBFSC 6x6

No. of Heads/Syringes

Six

No. of Capping Head

Six

Fill Capacity

50ml to 250ml with the help of change parts

Fill Accuracy

+  1%

Output/Minute

60 to 90 Bottles depending on viscosity & fill volume

Working direction

Left to Right

Electric Characteristic

Main Motor

3.75 HP/230V/1440 RPM/Single Phase/50 Hz

Conveyor Motor

0.5 HP/230V/1440 RPM/Single Phase/50 Hz

Power Supply

Single Phase/3 Phase, 4 Wire

Input Specifications

Bottle dia.

20mm to 75mm

Bottle height

25mm to 170mm

Overall dimensions

3450 mm L x 1156 mm W x 2500 mm H

Net Weight

1600 kgs.

Gross Weight

1900 kgs.

(The above specifications may change with the inclusion of latest technologies)

AUTOMATIC 8 x 8 HEAD LINEAR BOTTLE LIQUID FILLING & ROPP CAPPING MACHINE (MONOBLOCK)

MODEL: MBFRC 8x8

On-line filled containers are fed and guided on the moving SS/Plastic slat conveyor belt at the required speed enter in to infeed feed worm which transfers the bottle into infeed starwheel. The filled bottle moving in star wheel pick up cap from the cap chute and move under the Cap Pressing Head for perfect Cap Pressing on filled bottle. Then after the bottles moves on conveyor via outfeed starwheel for next operation.

Technical Specifications:

Machine Model

MBFRC 8x8

No. of Heads/Syringes

Eight

No. of Capping Head

Eight

Fill Capacity

50ml to 250ml with the help of change parts

Fill Accuracy

+  1%

Output/Minute

90 to 120 Bottles depending on viscosity & fill volume

Working direction

Left to Right

Electric Characteristic

Main Motor

3.75 HP/230V/1440 RPM/Single Phase/50 Hz

Conveyor Motor

0.5 HP/230V/1440 RPM/Single Phase/50 Hz

Power Supply

Single Phase/3 Phase, 4 Wire

Input Specifications

Bottle dia.

20mm to 75mm

Bottle height

25mm to 170mm

Overall dimensions

36500 mm L x 1156 mm W x 2500 mm H

Net Weight

1700 kgs.

Gross Weight

2000 kgs.

(The above specifications may change with the inclusion of latest technologies)
